MOQ: | Negotiable |
Price: | Negotiable |
Item | Mobile | ||
---|---|---|---|
Model | P-2.5R | P-3.33R | P-5R |
Pixel Pitch(mm) | 2.5mm | 3.33mm | 5mm |
Pixel Density(dot/sqm) | 160,000 | 90,180 | 40,000 |
LED Type | SMD2121(1921) | SMD1921 | SMD1921 |
Module Size(WXH)mm | 320x320 | 320x320 | 320x320 |
Module Resolution(WXH) | 128x128 | 96x96 | 64x64 |
Module Weight(Kg) | 0.32 | 0.32 | 0.28 |
Power Consumption per Module(W) | 40~80 | 40~70 | 30~48 |
Driver Mode(Scan) | 1/16 | 1/12 | 1/8 |
Brightness(cd/sqm) | ≥1,200(2500~4700) | 2500~4700 | 2500~4700 |
Gray Scale | 14 | 14 | 14 |
Refresh Rate(HZ) | ≥5100 | ≥5100 | ≥5100 |
Unit Size(WXH)mm | 1102x405x135 | ||
Display Size(WxH) | 960x320 | ||
Display Resolutiuon(WxH) | 384x128 | 288x96 | 192x64 |
Unit Weight(KG/PC) | 15 | 15 | 15 |
Max Power Consumption(W/Sets) | ≤390 | ≤380 | ≤350 |
Average Power Consumption(W/sqm) | 120 | 120 | 120 |
Viewing Angle Horizontal | 120° | ||
Viewing Angle Vertical | 120° | ||
Mini View Distance(m) | 2 | 3 | 5 |
Operating Temperature(℃) | -10℃~40℃/14°F~104°F | ||
Storage Temperature(℃) | -20℃~50℃/-4°F~122°F | ||
Input Voltage | DC 12V | ||
Failure Rate | <1/50,000 | ||
Control Type | USB/Network/Wifi & 4G optional | ||
Life Time(hrs) | 100,000 | ||
IP Level | IP65 |
