Product Details:
|
| Piexl Pitch: | 2.5mm, 3.33mm, 5mm | Feature: | Waterproof Dustproof |
|---|---|---|---|
| Refresh Rate: | >5100 HZ | Average Power Consumption: | 120 W/SQM |
| Unit Weight: | 15 KG/PCS | Module Size: | 320mm X 320mm |
| Brightness: | 2500nits ~ 4700nits | ||
| High Light: | IP65 Taxi Top LED Signs,Taxi Top LED Signs Dustproof,LED Taxi Display SMD2121 |
||
Aluminum Case with Oxidation treatment, coating film for unti ultraviolet, outdoor painting for anti-rusting and anti-aging
Web Control and could manage in anytime and any location through web browser. No need for download software.
Easy installation bracket, fast maintenance structure
Supports 3G-4G WIFI Internet connection. Quickly and simply change your content anytimeand anywhere.
Ensure its operability and safety, we did shock test.
With total weight about 15Kg per unit, durable enough for outdoor use.
Change Advertisment by location, such as show KFC video when Taxi led sign arrive KFC shop
| Item | Mobile | ||
|---|---|---|---|
| Model | P-2.5R | P-3.33R | P-5R |
| Pixel Pitch(mm) | 2.5mm | 3.33mm | 5mm |
| Pixel Density(dot/sqm) | 160,000 | 90,180 | 40,000 |
| LED Type | SMD2121(1921) | SMD1921 | SMD1921 |
| Module Size(WXH)mm | 320x320 | 320x320 | 320x320 |
| Module Resolution(WXH) | 128x128 | 96x96 | 64x64 |
| Module Weight(Kg) | 0.32 | 0.32 | 0.28 |
| Power Consumption per Module(W) | 40~80 | 40~70 | 30~48 |
| Driver Mode(Scan) | 1/16 | 1/12 | 1/8 |
| Brightness(cd/sqm) | ≥1,200(2500~4700) | 2500~4700 | 2500~4700 |
| Gray Scale | 14 | 14 | 14 |
| Refresh Rate(HZ) | ≥5100 | ≥5100 | ≥5100 |
| Unit Size(WXH)mm | 1102x405x135 | ||
| Display Size(WxH) | 960x320 | ||
| Display Resolutiuon(WxH) | 384x128 | 288x96 | 192x64 |
| Unit Weight(KG/PC) | 15 | 15 | 15 |
| Max Power Consumption(W/Sets) | ≤390 | ≤380 | ≤350 |
| Average Power Consumption(W/sqm) | 120 | 120 | 120 |
| Viewing Angle Horizontal | 120° | ||
| Viewing Angle Vertical | 120° | ||
| Mini View Distance(m) | 2 | 3 | 5 |
| Operating Temperature(℃) | -10℃~40℃/14°F~104°F | ||
| Storage Temperature(℃) | -20℃~50℃/-4°F~122°F | ||
| Input Voltage | DC 12V | ||
| Failure Rate | <1/50,000 | ||
| Control Type | USB/Network/Wifi & 4G optional | ||
| Life Time(hrs) | 100,000 | ||
| IP Level | IP65 | ||
