The technical issues that have always plagued the LED industry
2024-12-12
Static electricity damage problem
Since 1998, The LED display industry has been continuously improving its formal lead packaging technology for over 20 years, but so far no company has promised to prevent electrostatic discharge (ESD) damage to lamp beads at 2000V
Lamp bead failure rate issue
From 2012 to 2019, it took the LED display industry 7 years to perfect the assembly components. But there is no LED packaging manufacturer in the industry that can promise customers a 20PPM LED bead failure rate
Heat dissipation and power consumption issues
Since 2001, The LED display industry has been working for 20 years without solving the problems of high brightness, heat dissipation, and power consumption of indoor SMD light beads above 3500CD.
To solve the above industry problems, it is necessary to introduce:
Inverted chip technology, common cathode packaging technology, and common cathode driving technology
View More

LED display gray scale identification level and brightness identification level test
2023-10-08
LED display gray scale identification level and brightness identification level test
ALISEN specializes in commercial displays
The grayscale level of ALISEN LED displays depends mainly on the number of A/D conversion bits of the system. Of course, the system's video processing chip, memory and transmission system should provide the appropriate number of bits to support. Currently ALISEN domestic LED display mainly uses 8-bit processing system, that is, 256 (28) levels of gray scale. Simple to understand is from black to white there are 256 kinds of brightness changes. Using RGB three primary colors can constitute 256 × 256 × 256 = 16777216 kinds of colors, that is, usually referred to as 16 trillion colors.ALISEN international brand display mainly uses 10-bit processing system, that is, 1024 levels of grayscale, RGB three primary colors can be composed of 1.07 billion colors.
Although the gray scale is the determining factor in deciding the number of colors, it is not that the larger the better without limit. Because the resolution of the human eye is limited, and then the increase in the number of bits of system processing will involve the system video processing, storage, transmission, scanning and other aspects of the change, the cost of a sharp increase in cost-effective rather than decline. Generally speaking, civil or commercial grade products can be used 8-bit system, broadcast grade products can be used 10-bit system.
ALISEN Brightness identification level:
The brightness discrimination level of ALISEN LED display refers to the brightness level between the blackest and whitest images that the human eye can distinguish.
As mentioned earlier, some gray levels are very high and can reach 256 levels or even 1024 levels. However, due to the limited sensitivity of the human eye to brightness, and can not fully recognize these gray levels. That is to say, there may be many adjacent levels of grayscale human eyes look the same.
Moreover, the eye's ability to recognize these levels varies from person to person. For LED display, the human eye to recognize the level is naturally the more the better, because the image displayed is, after all, for people to see. The more luminance levels the human eye can distinguish means the larger the color space of the display and the greater the potential to display rich colors.
Brightness identification level can be tested with special software, the general display can reach more than 20 levels even if it is a better level.
View More

Trends of the Four Major Segments in the Display Industry
2024-12-12
On July 3, Eric Chiou, Senior Research Vice President at TrendForce, was invited to speak
at the Display Innovation China Forum 2024 (the 2024 DIC FORUM) in Shanghai.
Chiou delivered a speech titled "The Rise, Development, Transformation,
and Integration of Four Major Display Technologies," and the content is as follows.
TrendForce analyzed the development of four major display technologies by focusing on their rise,
development, transformation, and integration, delving into the future of the display industry.
View More

Top 3 connectors brand especially used in rental led display
2023-03-28
In the current LED rental display industry, aviation plugs and sockets are also widely used in products.
The power sockets, signal sockets, power cables and signal cables of standard LED display products are connected by aviation plugs and sockets. especially large LED screens.
Aviation plugs and sockets are commonly used in technology to connect each independent small LED display.
Aviation plugs and sockets play the role of parallel and series connection of up, down, left and right power lines and signal lines in LED display splicing. The aviation head is a crucial part of the LED display screen.
The top three brands are as follows:
Neutrik
Neutrik AG is an international company with a history of over forty years. The company was founded in 1975 by Bernhard Weingartner and the owners of NeuElektrik AG, Gebhard Sprenger and Josef Gstoehl, with the aim of creating innovative products for the connection between mechanics and electronics. Today, Neutrik is a world leader in the design, production and sale of a wide range of connectors.
Linko
Shenzhen Linko Electric Co., Ltd., founded in 2004, is a national high-tech enterprise integrating R&D, production, sales and service of industrial waterproof connector products.
Adhering to the business philosophy of “leading technology, lean management, customer first, and win-win cooperation”, the company continues to provide global customers with high-end connectivity solutions and products. And with good reputation and service, it has become the preferred partner of global engineers.The company’s main business involves various industrial connectors such as power connectors, signal connectors, data connectors, and customized wiring harness products. At present, the products are widely used in LED display and other fields. Linke Electric’s products have obtained professional certifications from China, the United States, the European Union and other countries. The company has won the national innovative enterprise certification, the national “AAA credit enterprise”.
Seetronic
It is a high-tech enterprise specializing in the development of mid to high-end connectors. Relying on Taiwan's foundation of precision machining, and with a highly forward-looking and creative design team, they continuously develop outstanding products that meet market demand for generations to lead current and future needs. Especially with the rise of many emerging industries, they are also expanding their horizons to meet those new needs in a timely manner, Provide us with customized solutions. Seetronic's products cover connectors for audio, video, signal, power, and optical fiber.
View More

What are the scenarios of indoor small-pitch led display applications?
2023-03-27
What are the scenarios of indoor small-pitch led display applications?
With the continuous development and improvement of LED technology, indoor LED display, especially small pitch products with its seamless splicing, high refresh rate, high definition, low energy consumption, long life and other advantages are increasingly favored by the market. So what are the common application areas and use scenarios of indoor small pitch led display?
1, live room, TV studio
Live studio, TV studio video background applications, the anchor background video wall is the most typical, live room, studio on the display panel color temperature, brightness, gray scale, perspective, contrast, refresh rate and other technical indicators requirements are quite demanding. Small pitch led display in the technical indicators can meet the application of such scenes, and LED display because of no slit, unit size is small, can easily meet the internal arc dance design, in contrast, color and other aspects is better than other panels, so the broadcasting application will be an important territory of high-definition LED.
2、Corporate meeting room
Small pitch led display is very suitable for application in the company enterprise conference room video conferencing system display terminal, conference room configuration small pitch led display can not only enhance the corporate image of the company, more enhance the conference effect.
3、Smart city construction
In the field of smart city construction, the monitoring center and command center of public security, traffic and people's livelihood are using small-pitch led display more and more commonly.
View More
