Dustproof Advertising LED Display Shelf Retail Shop Digital SMD1010 P1.8
Product Details:
| Brand Name: | AlisenLED |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | 25 Working Days |
| Payment Terms: | T/T |
|
Detail Information |
|||
| Name: | Commercial LED Display Screen | Brightness: | 600nits ~ 800nits |
|---|---|---|---|
| Feature: | Dustproof Waterproof | LED Type: | COB |
| Cabinet Material: | Die-Casting Aluminum | Resolution: | 1280x720 |
| Highlight: | Dustproof Advertising LED Display,Advertising LED Display P1.8,LED Display Shelf SMD1010 |
||
Product Description
Smart LED Shelf Display Retail Shop Digital For Supermarket Advertising Digital Signage
Vivid Performance
High refresh rate, high gray scale, great color saturation and intelligent color temperature adjustment which make the visual effect of our SF series LED display more vivid.
Suitable for Different Shelves
SF is designed for different types of shelves; it can be placed in shopping malls, supermarkets, retail stores, etc
Light and Thin, Easy Installation
22mm cabinet thickness and 1.5kg weight make SF lighter and thinner than most LED shelf displays in the market.
Water-proof and Collision-Resistant
High-tech GOB raises the level of protection up to IP65, which protects the screen from being damaged by water and collision.
Easy to control
Advanced controlling system enables the screen to "plug and play". What's more, the content of display can be changed via cloud-base anywhere anytime.
Application Fields
Shelf LED screen can play various videos and pictures.
It always shows attractive videos and pictures display effects to our customers.
| Item | nbsp; | P1.8 |
|---|---|---|
| Pixel Pitch | nbsp; | 1.875mm |
| Led Type | nbsp; | SMD1010 |
| Module Resolution | nbsp; | 160dots x 32dots |
| Driving Mode | nbsp; | 1/32 Scan |
| Module Pixels | nbsp; | 5,120 dots |
| Module Size | nbsp; | 300mm x 60mm |
| Cabinet Size | nbsp; | 600mm x 60mm or 900mm x 60mm |
| Cabinet Resolution | nbsp; | 320dots x 32dots or 480dots x 32dots |
| Pixel Density | nbsp; | 284,444.44 dots/sqm |
| Minimum Viewing Distance | nbsp; | ≥1.8 m |
| Brightness | nbsp; | 800nits ~ 1,000nits |
| IP Grade | nbsp; | IP43 Or IP65 (With GOB technology) |
| Refresh Rate | nbsp; | 1,920 ~ 3,840HZ |
| Gray Scale | nbsp; | 13bits ~ 24bits |
| Viewing Angle | nbsp; | H:160°/ V:160° |
| Maxmum Power Consumption | nbsp; | 800W/sqm |
| Average Power Consumption | nbsp; | 230W/sqm |
| Input Voltage | nbsp; | AC110V ~ AC220V @50/60HZ |
| Operating Temperature | nbsp; | -20℃ ~ 65℃ |
| Operating Humidity | nbsp; | 10% ~ 90% |
| Cabinet Material | nbsp; | Aluminum |
| Cabinet Weight | nbsp; | 1.2 kg or 1.5kg/panel |
| Operating System | nbsp; | Windows(win7,Win8,Win10,etc) |
| Signal Source Compatibility | nbsp; | DVI, HDMI1.3, DP1.2, SDI, HDMI2.0, etc |
