Home > products > Commercial LED Display Screen > P1.875 Commercial LED Display Screen COB Shelf Retail Digital Display 5VDC

P1.875 Commercial LED Display Screen COB Shelf Retail Digital Display 5VDC

Product Details

Model Number: SHEL-COB-P1.875mm-600mm

Payment & Shipping Terms

Minimum Order Quantity: Negotiable

Price: Negotiable

Packaging Details: Wooden Case

Delivery Time: 25 Working Days

Payment Terms: T/T

Get Best Price
Highlight:

P1.875 Commercial LED Display Screen

,

Commercial LED Display Screen COB

,

Retail Digital Display 5VDC

Name:
P1.875mm Commercial Led Display COB Shelf 600mm X 60mm
Pixel Pitch:
1.875mm
Length:
600mm
Power Supply Mode:
5VDC Or 24VDC
Brightness:
300 ~ 1000 Nits
Resolution:
30 X 480
Power Consumption:
48 W
Contrast:
1,000,000 : 1
Horizontal Viewing Angle:
170 Degree
Vertical Viewing Angle:
170 Degree
Name:
P1.875mm Commercial Led Display COB Shelf 600mm X 60mm
Pixel Pitch:
1.875mm
Length:
600mm
Power Supply Mode:
5VDC Or 24VDC
Brightness:
300 ~ 1000 Nits
Resolution:
30 X 480
Power Consumption:
48 W
Contrast:
1,000,000 : 1
Horizontal Viewing Angle:
170 Degree
Vertical Viewing Angle:
170 Degree
P1.875 Commercial LED Display Screen COB Shelf Retail Digital Display 5VDC

P1.875mm Commercial Led Display COB Shelf 600mm X 60mm Retail Shop Digital Display



Vivid Performance

High refresh rate, high gray scale, great color saturation and intelligent color temperature adjustment which make the visual effect of our SF series LED display more vivid.

Suitable for Different Shelves

SF is designed for different types of shelves; it can be placed in shopping malls, supermarkets, retail stores, etc

Light and Thin, Easy Installation

22mm cabinet thickness and 1.5kg weight make SF lighter and thinner than most LED shelf displays in the market.

Water-proof and Collision-Resistant

High-tech GOB raises the level of protection up to IP65, which protects the screen from being damaged by water and collision.

Easy to control

Advanced controlling system enables the screen to "plug and play". What's more, the content of display can be changed via cloud-base anywhere anytime.

Application Fields

Shelf LED screen can play various videos and pictures.
It always shows attractive videos and pictures display effects to our customers.


Item P1.8
Pixel Pitch 1.875mm
Led Type SMD1010
Module Resolution 160dots x 32dots
Driving Mode 1/32 Scan
Module Pixels 5,120 dots
Module Size 300mm x 60mm
Cabinet Size 600mm x 60mm or 900mm x 60mm
Cabinet Resolution 320dots x 32dots or 480dots x 32dots
Pixel Density 284,444.44 dots/sqm
Minimum Viewing Distance ≥1.8 m
Brightness 800nits ~ 1,000nits
IP Grade IP43 Or IP65 (With GOB technology)
Refresh Rate 1,920 ~ 3,840HZ
Gray Scale 13bits ~ 24bits
Viewing Angle H:160°/ V:160°
Maxmum Power Consumption 800W/sqm
Average Power Consumption 230W/sqm
Input Voltage AC110V ~ AC220V @50/60HZ
Operating Temperature -20℃ ~ 65℃
Operating Humidity 10% ~ 90%
Cabinet Material Aluminum
Cabinet Weight 1.2 kg or 1.5kg/panel
Operating System Windows(win7,Win8,Win10,etc)
Signal Source Compatibility DVI, HDMI1.3, DP1.2, SDI, HDMI2.0, etc
