Alisenled Indoor P2.6 P2.9 P3.9 Led Wall Screen Truss Hanging 500mm x 500mm Led Display Screen Panel

Product Details

Place of Origin: China

Brand Name: AlisenLED/OEM/ODM

Certification: CE/FCC/CB/IECEE/ibs

Model Number: P2.6-500X500

Payment & Shipping Terms

Minimum Order Quantity: Negotiable

Price: Negotiable

Packaging Details: Flight Case or wooden case

Delivery Time: 7-25 Working days

Payment Terms: T/T, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability: 5000SQM/month

Get Best Price
Highlight:

1920HZ Indoor LED Display

,

P2.6mm Indoor LED Display

,

1920HZ LED Video Wall Rental

LED Pitch:
P1.9, P2.6, P2.9, 3.91 4.81
Brightness:
> 800nits
Color:
RGB Full Color
Component:
Die-Casting Aluminum
Utilization:
Advertising Publish, Retail Store, Shopping Mall, Display Of Dishes, Welcome Display, Self-service Business, Exhibition Hall, Wayfinding, Airport, Subway, Elevator, Restaurant & Hotel Supplies, Education, Medical Treatment
Curved Lock:
Yes
Cabinet Size:
500X500mm,500mm X 1000mm
Module Size:
250mm X 250mm
Refresh Rate:
> 3840HZ
Curved Locks:
With Curved Locks
GOB:
Can Do GOB Available
Suppier Type:
Original Manufacturer, ODM, Agency, Retailer, OEM, Other
Warranty:
3years
LED Pitch:
P1.9, P2.6, P2.9, 3.91 4.81
Brightness:
> 800nits
Color:
RGB Full Color
Component:
Die-Casting Aluminum
Utilization:
Advertising Publish, Retail Store, Shopping Mall, Display Of Dishes, Welcome Display, Self-service Business, Exhibition Hall, Wayfinding, Airport, Subway, Elevator, Restaurant & Hotel Supplies, Education, Medical Treatment
Curved Lock:
Yes
Cabinet Size:
500X500mm,500mm X 1000mm
Module Size:
250mm X 250mm
Refresh Rate:
> 3840HZ
Curved Locks:
With Curved Locks
GOB:
Can Do GOB Available
Suppier Type:
Original Manufacturer, ODM, Agency, Retailer, OEM, Other
Warranty:
3years
Alisenled Indoor P2.6 P2.9 P3.9 Led Wall Screen Truss Hanging 500mm x 500mm Led Display Screen Panel

Product Description



High Definition



Alisenled Indoor P2.6 P2.9 P3.9 Led Wall Screen Truss Hanging 500mm x 500mm Led Display Screen Panel 0

Alisenled Indoor P2.6 P2.9 P3.9 Led Wall Screen Truss Hanging 500mm x 500mm Led Display Screen Panel 1Alisenled Indoor P2.6 P2.9 P3.9 Led Wall Screen Truss Hanging 500mm x 500mm Led Display Screen Panel 2Alisenled Indoor P2.6 P2.9 P3.9 Led Wall Screen Truss Hanging 500mm x 500mm Led Display Screen Panel 3Alisenled Indoor P2.6 P2.9 P3.9 Led Wall Screen Truss Hanging 500mm x 500mm Led Display Screen Panel 4Alisenled Indoor P2.6 P2.9 P3.9 Led Wall Screen Truss Hanging 500mm x 500mm Led Display Screen Panel 5Alisenled Indoor P2.6 P2.9 P3.9 Led Wall Screen Truss Hanging 500mm x 500mm Led Display Screen Panel 6Alisenled Indoor P2.6 P2.9 P3.9 Led Wall Screen Truss Hanging 500mm x 500mm Led Display Screen Panel 7

Specification


Item P1.9 P2.6 P2.9 P3.9
Pixel Pitch 1.953mm 2.604mm 2.976mm 3.906mm
Led Type SMD1515 SMD1515 SMD2020 SMD2020
Module Resolution 128dots x 128dots 96dots x 96dots 84dots x 84dots 64dots x 64dots
Driving Mode 1/32 Scan 1/32 Scan 1/28 Scan 1/16 Scan
Module Pixels 16,384 dots 9,216 dots 7,056 dots 4,096 dots
Module Size 250mm x 250mm 250mm x 250mm 250mm x 250mm 250mm x 250mm
Cabinet Size 500mm x 500mm 500mm x 500mm 500mm x 500mm 500mm x 500mm
Cabinet Resolution 256dots x 256dots 192dots x 192dots 168dots x 168dots 128dots x 128dots
Pixel Density 262,144 dots/sqm 147,456 dots/sqm 112,896 dots/sqm 65,536 dots/sqm
Minimum Viewing Distance ≥1.9 m ≥2.6 m ≥2.9 m ≥3.9 m
Brightness 600nits ~ 800nits 600nits ~ 1200nits 600nits ~ 1200nits 800nits ~ 1200nits
IP Grade IP43 IP43 IP43 IP43
Refresh Rate 1,920HZ ~ 3840HZ 1,920HZ ~ 3840HZ 1,920HZ ~ 3840HZ 1,920HZ ~ 3840HZ
Gray Scale 14bits ~ 24bits 14bits ~ 24bits 14bits ~ 24bits 14bits ~ 24bits
Viewing Angle H:160°/ V:160° H:160°/ V:160° H:160°/ V:160° H:160°/ V:160°
Maxmum Power Consumption 560W/sqm 560W/sqm 560W/sqm 560W/sqm
Average Power Consumption 160W/sqm 160W/sqm 160W/sqm 160W/sqm
Input Voltage AC110V ~ AC220V @50/60HZ AC110V ~ AC220V @50/60HZ AC110V ~ AC220V @50/60HZ AC110V ~ AC220V @50/60HZ
Operating Temperature -20℃ ~ 65℃ -20℃ ~ 65℃ -20℃ ~ 65℃ -20℃ ~ 65℃
Operating Humidity 10% ~ 90% 10% ~ 90% 10% ~ 90% 10% ~ 90%
Cabinet Material Die-casting Aluminum Die-casting Aluminum Die-casting Aluminum Die-casting Aluminum
Cabinet Weight 7.5 kg/panel 7.5 kg/panel 7.5 kg/panel 7.5 kg/panel
Operating System Windows(win7,Win8,Win10,etc) Windows(win7,Win8,Win10,etc) Windows(win7,Win8,Win10,etc) Windows(win7,Win8,Win10,etc)
Signal Source Compatibility DVI, HDMI1.3, DP1.2, SDI, HDMI2.0, etc DVI, HDMI1.3, DP1.2, SDI, HDMI2.0, etc DVI, HDMI1.3, DP1.2, SDI, HDMI2.0, etc DVI, HDMI1.3, DP1.2, SDI, HDMI2.0, etc


Application



Alisenled Indoor P2.6 P2.9 P3.9 Led Wall Screen Truss Hanging 500mm x 500mm Led Display Screen Panel 8

Alisenled Indoor P2.6 P2.9 P3.9 Led Wall Screen Truss Hanging 500mm x 500mm Led Display Screen Panel 9

Alisenled Indoor P2.6 P2.9 P3.9 Led Wall Screen Truss Hanging 500mm x 500mm Led Display Screen Panel 10



Package&Delivery

Alisenled Indoor P2.6 P2.9 P3.9 Led Wall Screen Truss Hanging 500mm x 500mm Led Display Screen Panel 11Alisenled Indoor P2.6 P2.9 P3.9 Led Wall Screen Truss Hanging 500mm x 500mm Led Display Screen Panel 12Alisenled Indoor P2.6 P2.9 P3.9 Led Wall Screen Truss Hanging 500mm x 500mm Led Display Screen Panel 13

FAQ

Q1: What is the control system? How is it?
A: We use Nova Taurus Series asynchronous control system. Support cluster play and management. Support APP/Phone/ WIFI/ Ipad/ Laptop/ PC/ Cloud control. It’s very easy and convenient to control.

Q2: Can I have a sample order for led screen?
A: Yes, we welcome sample order to test and check quality. Mixed samples areacceptable.

Q3:Is it OK to print my logo on product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q4: What is your best service?
1: One to one sales engineer to customer responsibility system;
2. Know your project and provide the best solution for it;
3. Track your order and let you know each step and detail of it;
4. Teach you how to install and use the screen;
5. Care the subsequent use of your screen and ensure your after - sales service be well.

Q5. How about your delivery time?
A: Generally, it will take 7-15 days after receiving your deposit. The specific delivery time depends on the items and the quantity of your order.

Q6:How about your Warranty Term?
A: 3-5years warranty. Structure design, installation problem, system problem, how to use the screen…don’t worry, we have professional after-sale team to solve your any questions after you placed an order. And your exclusive sales engineer will also help you get over any problems.
