Product Details:
|
| Pixel Pitch: | P2mm | Module Size: | 320mmx160mm |
|---|---|---|---|
| Screen Size: | 640mm X 1920mm | Screen Resolution: | 320x960 Dots |
| LED Type: | SMD1515 | Pixel Density: | 250,000 Dots/Sqm |
| Cabinet Weight: | 40Kg | Scanning Mode: | 1/40 S |
| View Angle: | H:140 Degree; V:140 Degree | Usage: | Shopping Mall, Exhibition Hall, Events, Showroom |
| High Light: | Showroom LED Banner Display,P2 LED Banner Display,SMD1515 Full Color LED Poster |
||
Poster LED display is ultra-thin and super-light, it can be fixed by magnet and screws two ways.
It fixed by magnets, you can maintain LED display from both front side and rear side.
Our product is 50% lighter than normal digital LED banner thanks to its excellent cabinet design.
This LED screen has 60% longer lifespan than normal totem LED display because of low attenuation.
Poster LED Display with bracket that can stand on floor directly, you can also hang it on wall if necessary.
It is perfect alternatives for tranditional poster. Poster LED display usually used for restaurant, shopping mall, stores, schools etc.
Full screen can display images without any black area. The image area is bigger and the color contrast is higher. Besides, this LED poster's brightness can reach more than 800nits. The visual performance is superior.
As a LED poster, this product is 40% thinner than normal similar ones in the market.
Excellent cabinet design gives this indoor fixed LED display screen unlimited possibilities.
Putting multiple screens together, it will be perform like a big display.
You won't even notice the stitching gap between screens.
Benefiting from professional cabinet design and the higher quality materials, It enhances advertising effects.
As an advertising player, this product is able to catch customers attention quickly with its splendid performance.
As an indoor Advertising player, it is usually used in the shopping plaza or in front of stores, displaying advertisements.
The completeness of pictures and videos played on the screen offers you extraordinary visual experience.
| Item | P1.86 | P2 | P2.5 | P3 |
|---|---|---|---|---|
| Pixel Pitch | 1.86mm | 2mm | 2.5mm | 3mm |
| Led Type | SMD1515 | SMD1515 | SMD2020 | SMD2020 |
| Driving Mode | 1/43 Scan | 1/40 Scan | 1/32 Scan | 1/32 Scan |
| Screen Resolution | 344x1032 dots | 320x960 dots | 256x768 dots | 192x640 dots |
| Module Size | 320mm x 160mm | 320mm x 160mm | 320mm x 160mm | 192mm x 192mm |
| Screen Size | 640mm x 1,920mm | 640mm x 1,920mm | 640mm x 1,920mm | 570mm x 1,920mm |
| Pixel Density | 289,050 dots/sqm | 250,000 dots/sqm | 160,000 dots/sqm | 111,111 dots/sqm |
| Minimum Viewing Distance | ≥2 m | ≥2 m | ≥3 m | ≥4 m |
| Brightness | ≥800 nits | ≥800 nits | ≥800 nits | ≥800 nits |
| IP Grade | IP43 | IP43 | IP43 | IP43 |
| Refresh Rate | 1,920HZ ~ 3840HZ | 1,920HZ ~ 3840HZ | 1,920HZ ~ 3840HZ | 1,920HZ ~ 3840HZ |
| Gray Scale | 13bits ~ 24bits | 13bits ~ 24bits | 13bits ~ 24bits | 13bits ~ 24bits |
| Viewing Angle | H:140°/ V:140° | H:140°/ V:140° | H:140°/ V:140° | H:140°/ V:140° |
| Maxmum Power Consumption | 850W/sqm | 850W/sqm | 850W/sqm | 850W/sqm |
| Average Power Consumption | 260W/sqm | 260W/sqm | 260W/sqm | 260W/sqm |
| Input Voltage | AC110V ~ AC220V @50/60HZ | AC110V ~ AC220V @50/60HZ | AC110V ~ AC220V @50/60HZ | AC110V ~ AC220V @50/60HZ |
| Operating Temperature | -20℃ ~ 65℃ | -20℃ ~ 65℃ | -20℃ ~ 65℃ | -20℃ ~ 65℃ |
| Operating Humidity | 10% ~ 90% | 10% ~ 90% | 10% ~ 90% | 10% ~ 90% |
| Cabinet Material | Iron | Iron | Iron | Iron |
| Cabinet Weight | 40 kg/panel | 40 kg/panel | 40 kg/panel | 40 kg/panel |
| Operating System | Windows(win7,Win8,Win10,etc) | Windows(win7,Win8,Win10,etc) | Windows(win7,Win8,Win10,etc) | Windows(win7,Win8,Win10,etc) |
| Signal Source Compatibility | DVI, HDMI1.3, DP1.2, SDI, HDMI2.0, etc | DVI, HDMI1.3, DP1.2, SDI, HDMI2.0, etc | DVI, HDMI1.3, DP1.2, SDI, HDMI2.0, etc | DVI, HDMI1.3, DP1.2, SDI, HDMI2.0, etc |
