Single / Mono Color LED Display Module , 320mm * 160mm 1R Pixel IP65 LED Panel Module

Single / Mono Color LED Display Module , 320mm * 160mm 1R Pixel IP65 LED Panel Module

    • Single / Mono Color LED Display Module , 320mm * 160mm 1R Pixel IP65 LED Panel Module
    • Single / Mono Color LED Display Module , 320mm * 160mm 1R Pixel IP65 LED Panel Module
  • Single / Mono Color LED Display Module , 320mm * 160mm 1R Pixel IP65 LED Panel Module

    Product Details:

    Place of Origin: China
    Brand Name: Viso
    Certification: UL CE ROHS ISO ETL SGS SAA Fcc EMC
    Model Number: PH10 DIP Red 16x32

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 PCS / 1 Unit
    Price: Negotiation
    Packaging Details: Carton box or Wooden case
    Delivery Time: 4-6 work days
    Payment Terms: L/C, T/T, Western Union, Paypal, Credit Card, MoneyGram, VISA
    Supply Ability: 8,000 square meters per month
    Contact Now
    Detailed Product Description
    Pixel Configuration: 1R Pixel Pitch: 10mm
    Waterproof: IP65 Life Span: 100000hours
    Max Power Consumption: 26W Pixel Density: 10000dots/m2
    Drive Type: 1/4 Scanning Module Resolution: 16*32
    Storage Temperature: -40°C~60°C

    Single /Mono Color LED Display Module , 320mm * 160mm 1R Pixel IP65 LED Modules for Sign

    Product Description:
    1) High brightness and stable picture.
    2) Long lifetime
    3) Reducing power consumption by 50% and has passed the inspection by the national inspection authorities


    outdoor single color red led display module P10 320mm*160mm

    Technical Specification:

    LED ConfigurationDIP 1R
    Pixel Pitch10 mm
    Pixel Density10.000dots/m2
    Chip Color1R
    Module Size320mm*160mm
    Module Density32*16
    Display Weight0.5KG/pcs
    Viewing Distance≥10 m
    Viewing AngleV/H 120°/45°
    Maximum Power Consumption≤800W/m2
    Average Power Consumption≤400W/m2
    Drive Method1/4 scan Constant Voltage
    Frame Rate≥60Hz
    Refresh Rate≥300Hz
    Brightness≥5500cd/m2
    Environment Temperature-20°C~60°C
    Working Current220V±15% or 110V±15% 50~60Hz
    Grey Scale256 (synchronized)
    Method of Brightness Adjustment256
    MTBF≥9,000h
    Lifetime≥100,000h
    Dead Dot≤0.0003


    1. Wide application field & short ROI time:
    commercial advertising LED display screen, Stadium perimeter LED display screen, Mobile trailer LED display screen for mobile media, shopping mall LED display screen for logo showing, bank&stock exchange LED display screen for rates showing, train & bus station LED display screen, air port LED display screen, telecommunication LED display screen system for information showing and instruction
    2. High Contrast ratio: 4000:1
    Which is a very high level to ensure a vivid image of our LED display screen system.
    3. First-class LED chip:
    Supplied by Nichia of Japan & other high strictly selected LED chip to ensure the long lifetime and high brightness of our LED display screen system
    4. Clear vivid image quality:
    Even in direct, full-on sunlight to ensure you attract more audience to get short ROI of your LED display screen's investment.::
    5. Long-term Brightness:
    Automatic or manual adjustment of the brightness of the display.
    6. Easy Installation & Using:
    easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system
    7. Convenient Servicing:
    Front and rear cabinet access makes the maintenance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion
