P6 / P10 / P20 3528 SMD LED Video Wall Panels , Outdoor Large Screen Display Solutions

P6 / P10 / P20 3528 SMD LED Video Wall Panels , Outdoor Large Screen Display Solutions

P6 / P10 / P20 3528 SMD LED Video Wall Panels , Outdoor Large Screen Display Solutions

Product Details:

Place of Origin: China
Brand Name: Vios
Certification: UL CE ROHS ISO ETL SGS SAA Fcc EMC
Model Number: PH5

Payment & Shipping Terms:

Minimum Order Quantity: 1 Square Meter Price
Price: Negotiation factory
Packaging Details: Wooden box or Flight case
Delivery Time: 4-6 work days
Payment Terms: L/C, T/T, Western Union, Paypal, Credit Card, MoneyGram, VISA
Supply Ability: 8,000 square meters per month
Contact Now
Detailed Product Description
Led Chip: Epistar/Cree/Nichia LED Type: RGB 3in1, SMD3528
Power Supply: Meanwell, AC90~260V, 50~60Hz Communication Mode: RJ45/USB/WIFI/3G
Driving Mode: 1/4 Scan Constant Current Working Temperature: -20°C-50°C
Life Span: >100,000hours Best Viewing Angle: 160°/120°
Input Signal: RF, S-VIDEO, RGBHV, YUN, YC & COMPOSITION Pixels: 10mm/12mm




Home video wal P6 / P10 / P20 3528 SMD LED Video Wall Panels , Outdoor Video Wall Solutions


Product Description:
* Light, suitable for flow shows, convenient in transporting and jointing.
* Nice appearance and secure.
* Jointed correctly, could be dismounted by one person without tool
* High transparency. Light, air and frost could easily cross through it.
* Humanized operating interface with breakdown indicator lights.
* High debugging brightness with 500-2000nit and no damage to gray scale, matched well with the debugging technology with nice image.


Application:
TV shows, live shows, events background display
Party, stage lighting
Hotel, disco, bars, night club ceiling and floor decoration
Architectures exterior lighting decoration
Totally transparent
Indoor use and can be places behind the glass
which can be viewed from outside



Technical Specification:

NameOutdoor DIP P10mm advertising LED Display screen
Module Size160*160mm
Pixel Distance10mm
Pixel Density10000 Pixels per Sqm.
Drive Method4 scanning
Chip1R 1G 1B DIP LED
Drive ChipMBI5020
Best Viewing Distance>8 meters
Viewing Angles60° (Vertical) 120° (Horizontal)
Life Span>100,000 Hours
Working Temperature-30~70 C°
Input VoltageAC110~270 V
Average Power(w/m2)450 W/m2
CertificationFCC, CE, RoHS,



pixel pitch6mm
parse of single module1024(32*32) dots
module size192*192mm
physical pixel density27777 dots/m2
LED pixel composing mode1R1G1B
Encapsulation modeSMD0805,SMD3528
Brightness1400cd - 1800cd/m2
VolfageDC5V
Max.Current10A
View angle120- 140
cabinet size576*768mm
cabinet resolution96*128 dots
cabinet weight28Kg
best viewing distance6-42m
drive modeConstant driving 1/8 scan
ave.consumption550 W/m2
max.consumption1100 W/m2
control mpdeSynchronism
graphic cardDVI Card
frame rate60HZ
refresh rate180HZ
white balance brightness1900cd/m2
computer systemWin98, WinXP, Win2000, etc
video signalRF, S-Video RGB, RGBHV, YUV, YC, COMPOSITION, etc.


P6 / P10 / P20 3528 SMD LED Video Wall Panels , Outdoor Large Screen Display Solutions
