High Resolution LED Display Full Color 3 In 1 16 X 32 Pixels P6 SMD 3535 / SMD 3528

High Resolution LED Display Full Color 3 In 1 16 X 32 Pixels P6 SMD 3535 / SMD 3528

High Resolution LED Display Full Color 3 In 1 16 X 32 Pixels P6 SMD 3535 / SMD 3528

Product Details:

Place of Origin: China
Brand Name: Viso
Certification: UL/CE/ROHS/FCC/ISO/EMC
Model Number: PH6.67

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs / 1 sqm
Price: negotiation factory price
Packaging Details: Wooden box or Flight case
Delivery Time: 4-6 work days
Payment Terms: L/C T/T Western Union Paypal Credit Card MoneyGram VISA
Supply Ability: 8,000 square meters per month
Contact Now
Detailed Product Description
LED Type: SMD3535 Density Of Pixel/(dots/m2): 22,478
Viewing Angle: 140 H,120 V Input Voltage: 110-220 VAC/+/- 10%
Luminance Of White Balance: ≥6000 Nits Certificates: CCC.CE.FCC.ROHS
Functionless Dot Rate: <0.0001




Rental led display high resolution led display 3 in 1 16 x 32 Pixels Full Color P6 SMD 3535 / SMD 3528

Product Features:
P6.25 full color vehicle advertising led screen is a high-quality product with thin structure, high definition and soft frame.
P6.944 full color vehicle advertising led screen .We have many kinds of version, like high refresh rate, and SMD 3528 and SMD 3535 for option.
Tn6 is a high-quality product with thin structure, high definition and soft frame; Each module make
use the special bar to connect for achieving fast assembly. Tn6 are suitably applied in vocal concerts,
clubs, nightclubs, DISCO and supermarket for the displaying and advertising use
1. Dust proof, IP43
2. Completely aluminum constitution, ultra thin and ultra light, wonderful in mixture color.
3. Large viewing angle, the panel viewing angle is up to 140, the vertical angle could reach 140, the
image won't be out of shape and color cast between the rang.
4. Could be exact connected and easy to install and dismount.



Technical Parameters:

P6.67P8
320x320320x320
22,47815,625
SMD3535SMD3535
48X4840X40
Optimum viewing distance7-75m
View angle / °140 H,120 V
Max power consumption/W/M21100
Size of cabinet/mm640X640
Resolution of cabinet96x96
Weight of cabinet/kg≥15
Driving method1/8 scan constant current
Refresh rate Hz/S≥2000
Luminance of white balance≥5000 nits
Operation of Environmental Temperature/°Cbelow 30 to above 50
Working voltage110-220 VAC/+/- 10%
Grey scale/colordisplaying colors≥16.7M(synchronized)
Brightness adjustment256 levels of each color,100 levels of each color
Input signalRF,S-Video,RGB,RGBH,YUV,YC&Composition
Control systemlinsn(sending card, receiving cards and Hubs)
Average of non-failure life>50,00h
Life span>100,000h
Functionless dot rate<0.0001


Led video screen xxxx is a kind of SMD outdoor full color LED display. It is specially designed for the indoor High Definition shows. LED lamp adopts standard 3in1 SMD technology. Every light unit is composed by red, green and blue color so the colors of the display can reach 1.07 billion kinds.
The indoor LED display can display colorful dynamic and static images in real time with perfect display effect. Thus, this LED display is the most significant display in all indoor full color screens.
The LED display supports usual VGA and DVI traditional video signal, also specially supports HDMI video signal and so on. In addition, it can receive and display video programs, such as TV programs, VCD or DVD, living show etc.
The products has high reliability, saturated and uniform color, hight brightness, low consumption, long service life and with wide angel sight. So the SMD full-color 3 in 1 indoor LED display is widely used in many indoor sites, such as show rooms, coffee house, hotel, stage and so on.
