Rental led display high resolution led display 3 in 1 16 x 32 Pixels Full Color P6 SMD 3535 / SMD 3528
P6.25 full color vehicle advertising led screen is a high-quality product with thin structure, high definition and soft frame.
P6.944 full color vehicle advertising led screen .We have many kinds of version, like high refresh rate, and SMD 3528 and SMD 3535 for option.
Tn6 is a high-quality product with thin structure, high definition and soft frame; Each module make
use the special bar to connect for achieving fast assembly. Tn6 are suitably applied in vocal concerts,
clubs, nightclubs, DISCO and supermarket for the displaying and advertising use
1. Dust proof, IP43
2. Completely aluminum constitution, ultra thin and ultra light, wonderful in mixture color.
3. Large viewing angle, the panel viewing angle is up to 140, the vertical angle could reach 140, the
image won't be out of shape and color cast between the rang.
4. Could be exact connected and easy to install and dismount.
|Optimum viewing distance||7-75m|
|View angle / °||140 H,120 V|
|Max power consumption/W/M2||1100|
|Size of cabinet/mm||640X640|
|Resolution of cabinet||96x96|
|Weight of cabinet/kg||≥15|
|Driving method||1/8 scan constant current|
|Refresh rate Hz/S||≥2000|
|Luminance of white balance||≥5000 nits|
|Operation of Environmental Temperature/°C||below 30 to above 50|
|Working voltage||110-220 VAC/+/- 10%|
|Grey scale/color||displaying colors≥16.7M(synchronized)|
|Brightness adjustment||256 levels of each color,100 levels of each color|
|Control system||linsn(sending card, receiving cards and Hubs)|
|Average of non-failure life||>50,00h|
|Functionless dot rate||<0.0001|
Led video screen xxxx is a kind of SMD outdoor full color LED display. It is specially designed for the indoor High Definition shows. LED lamp adopts standard 3in1 SMD technology. Every light unit is composed by red, green and blue color so the colors of the display can reach 1.07 billion kinds.
The indoor LED display can display colorful dynamic and static images in real time with perfect display effect. Thus, this LED display is the most significant display in all indoor full color screens.
The LED display supports usual VGA and DVI traditional video signal, also specially supports HDMI video signal and so on. In addition, it can receive and display video programs, such as TV programs, VCD or DVD, living show etc.
The products has high reliability, saturated and uniform color, hight brightness, low consumption, long service life and with wide angel sight. So the SMD full-color 3 in 1 indoor LED display is widely used in many indoor sites, such as show rooms, coffee house, hotel, stage and so on.
